Tempered Glass Door Accessories 180 Degree Brass Shower Glass Clamp Clips
This glass clamps product is available for distributors, glass shops, installers and project suppliers. It can be matched against a drawing, sample, photograph or required application.
Product Information
- Material: Brass
- Mounting Type: Glass-to-Glass
- Glass Thickness: 8 mm
- Opening Angle: 180°
- Door Application: Shower Door
Additional Supplier Specification
- Designed to Secure Fixed 180 Degree Inline Glass Panels Together
- For Use with 5/16" – 1/2" (8 mm to 12 mm) Tempered Glass
- Requires 3/4"（19mm）Diameter Hole for Installation
- Passes 72-Hour Salt Spray Test
- Personalize with up to ten different color and finish options → SVA-028 180 Degree Glass To Glass -Square Straight → SVA-035 180 Degree Glass To Glass-Square Beveled
Ordering & Product Matching
Quote requests should include model CHF-SVA-042, required quantity, glass thickness or opening dimensions, material and finish. OEM packaging and mixed-product orders can be discussed for distributor requirements.
Dimensions and technical suitability must be confirmed against the final drawing, sample or application before ordering.
